Axic Plasmamaster 200 Barrel Plasma Cleaner

PlasmaSTAR ® 200 A Unique Modular Approach to Barrel Plasma Processing The PlasmaSTAR® Series of Plasma Processing Systems from Axic, Inc. defines a new concept in barrel plasma processing. The systems are based on a modular design concept. Starting with a universal base unit, multiple electrode modules are available for easy insertion into the base unit. You will find the ease of use, variety of plasma processes, serviceability and attractive pricing unsurpassed by any other plasma system on the market. ? Interchangeable Electrode Modules ? Multiple Electrode Configurations: Cage, Tray, RIE, Downstream ? Proven Process Recipes ? Field Proven Components ? End-Point Detection (optional) ? Auto RF Matching ? Downstream Pressure Control (optional) ? Computer Controlled ? Touch Screen Operation ? Multiple Pumping Options SYSTEM DESCRIPTION In the research, process development and production of plasma processing, the need for a highly versatile and reliable tool is always in considerable demand. With the ever changing requirements in plasma research, the system selected must be capable of offering the widest range of process parameters, highest degree of repeatability for verifying the process and easily modified for new process require- ments. The PlasmaSTAR® series of dry process systems will satisfy the demanding requirements neces- sary to perform these tasks. The PlasmaSTAR® is a plasma tool used in research, process development and volume production for photo-resist striping and descuming, isotropic and an isotropic etching, organic ashing, hybrid circuit cleaning, printed circuit board desmearing, failure analysis, surface treat- ment and modification of plastics, polymer deposition, and a wide range of other plasma applications. The PlasmaSTAR® product line offers a uniquely new modular approach to barrel plasma systems. The PlasmaSTAR® will accommodate the processing of 200 mm or smaller substrates. (For single wafer RIE processing 300 mm wafers are readily processed) The selection of proven, quality components, modular subassemblies, versatile chamber-electrode design, compact size, automation and field proven process recipes will make the PlasmaSTAR® the “system of choice” for plasma process engineers. APPLICATIONS With the PlasmaSTAR®’s wide selection of chamber and electrode configurations the system is ca- pable of satisfying a wide range of plasma processing conditions. These processes range from simple surface cleaning to sophisticated submicron RIE etching. Axic, Inc., in conjunction with our large customer base has developed proven process recipes guaranteeing your system is up and processing from the day you install the system. Only the highest quality sub components are used in the manufacturing of the PlasmaSTAR® system providing the highest up-time, reliability, repeatability and serviceability. Typical processes include: ? Plasma Descuming ? Photo-Resist Stripping ? Surface Treatment ? Anisotropic & Isotropic Etching ? Failure Analysis Applications ? Material Modification ? Package Cleaning ? Passivation Etching ? Polyimide Etching ? Adhesion Promotion ? Biomedical Applications ? Polymerizaton ? Hybrid Cleaning ? Pre-Bond Cleaning SPECIFICATIONS                                                                                                                       The great success of the PlasmaSTAR® is due to its highly versatile design features. These features include a small foot- print for table top or laminar flow installation and modular chamber and electrode configurations for a wide variety of plasma processes. In addition the touch screen computer control provides easy operating and multi-level recipe con- trol, system operation and component control. Vacuum pumping options are available. Base System The universal base unit for all PlasmaSTAR® configura- tions contain all necessary valves, vacuum plumbing, RF power, RF matching, process gas control and system logic to provide a completely automated plasma processing system. The base unit is designed to accommodate a variety of cham- ber and electrode modules which are easily inserted into the base unit. Within a few minutes the system can be converted from a general barrel plasma processing system to a RIE, a Parallel Plate processing system, or a shelf cleaning system for hybrids. Chamber/Electrode The PlasmaSTAR® modular chamber and electrode as- semblies are a unique feature of the system. The chamber is hard anodized aluminum. Several different electrode designs are available which include water cooled (temperature con- trolled) parallel plate electrodes for RIE and Planar process- ing, alternating tray electrodes for surface cleaning or treat- ment, downstream electrodes for minimizing ion damage and cage electrodes for general barrel plasma processing. Plasma Sources The system is provided with a 600 watt 13.56 MHz power supply. An auto matching network is supplied. Process Pumping pumps are available depending on the necessary vacuum process- ing levels. The pumps are supplied with a corrosive series (inert pump fluid) for oxygen or corrosive chemistry applications. Two MFC controlled gas lines are standard with up to 2 additional available. Downstream pressure control is an option. Computer A touch screen controlled pentium computer is provided with unlimited recipe storage. Multi-step processes are easily accom- modated. Process conditions are continuously displayed. The unit is easily programmed and process protected. Process lots can be bar code read (optional). Options A wide selection of processing options are available for the Plasma-STAR® system increasing the system’s capabilities. Let us tell you more about the PlasmaSTAR® series of plasma processing systems by calling, e-mailing or faxing us. Please ask for our detailed pricing and specification sheet. We cordially in- vite you to either visit our applications laboratory or request a more detailed technical presentation on the PlasmaSTAR® series of systems. DIMENSIONS                                                      System - Width 35” x Depth 32” x Height 21” Chamber (interior) Width 14.75” x Depth 17” x Height 12” WEIGHT 150 lbs UTILITIES                                                          System 220 V 50/60 Hz, 15 Amps Pump 220 V (current depends on pump selection) H20          For Electrode Cooling (Electrode Dependent) Air For Valve Operation N The system is supplied with an optional mechanical pump 2 For chamber Vent or mechanical pump with roots blower. Various sizes of Gas          Process Gases
